Clip-ons Ø50mm
In stock
CO5002
- 7° inclination of the handlebar
- offset 41mm / tubes raised by 0 mm
- Ø22.2 mm (7/8") outer diameter of handlebar tube
- designed for Ø50 mm fork tubes
Components
Description
ARP Clip-ons Ø50 mm – clear front-end feedback, rigid construction and easy servicing
ARP clip-ons are designed for riders who want clear, direct feedback from the front tyre and a focused race setup. Their rigid construction and secure mounting help transmit feedback from the front end—especially under hard braking and fast direction changes.
One-piece fork clamps, a fixed 7° downward angle and adjustable tube extension provide a straightforward setup that allows you to fine-tune your riding position.
Geometry & materials
- Fork mounting diameter: Ø50 mm
- Fixed downward angle: 7°
- Offset: 41 mm
- Adjustable tube extension up to 260 mm
- One-piece fork clamps
- EN AW 6082 T6 aluminium
- Black anodised finish
- Stainless steel screws
The tubes can be moved within the clamps to adjust their extension. The downward angle is fixed.
Details & servicing
Removable black Delrin end caps with laser engraving provide access for fitting a compatible brake lever guard.
Handlebar tubes are individually replaceable, allowing a damaged tube to be replaced without purchasing a complete assembly. All spare parts are available on our website.
Universal fitment — check compatibility before ordering
These universal clip-ons are designed for forks with a Ø50 mm diameter at the mounting position. A matching diameter alone does not guarantee compatibility with your motorcycle.
Before ordering, check the product dimensions and available mounting space, including clearance around the upper triple clamp, fairing, fuel tank, controls and brake fluid reservoir. Brake hoses, throttle cables and wiring must remain unrestricted throughout the full steering range.
Depending on the motorcycle and setup, controls or other components may need to be repositioned.
Installation torque
M6 bolts: 10 Nm
Transport warning
Do not use the handlebars as tie-down points when transporting the motorcycle. This can seriously damage the fork tubes and clip-on clamps.
Track use only
For use on closed racing circuits only. Not approved for road use.
